Concrete Slab Mesh With High Strength And Rigidity For Reinforcement

Customer Reviews
Let’s talk business. Contact us and we will discuss further.

—— Dear customer

I'm Online Chat Now

Concrete Slab Mesh With High Strength And Rigidity For Reinforcement

Concrete Slab Mesh With High Strength And Rigidity For Reinforcement
Concrete Slab Mesh With High Strength And Rigidity For Reinforcement
Concrete Slab Mesh With High Strength And Rigidity For Reinforcement Concrete Slab Mesh With High Strength And Rigidity For Reinforcement Concrete Slab Mesh With High Strength And Rigidity For Reinforcement

Large Image :  Concrete Slab Mesh With High Strength And Rigidity For Reinforcement

Product Details:
Place of Origin: China
Brand Name: cittimesh
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: wooden packing
Delivery Time: Depends on the quantity of goods
Payment Terms: L/C, T/T

Concrete Slab Mesh With High Strength And Rigidity For Reinforcement

Description
Material: Stainless Steel. Surface Treatment: Hot Dipped Galvanized Or Electro Galvanized.
Variety: Truss Mesh Reinforcement Or Ladder Mesh Reinforcement. Tensile Strength: 510 MPa.
Minimum Impact Strength: 485 MPa.
Highlight:

High Strength Concrete Slab Mesh

,

Rigidity Concrete Slab Mesh

,

Reinforcement Concrete Slab Mesh



Concrete Slab Mesh with High Strength and Rigidity for Reinforcement



Concrete slab mesh is also called reinforced welded wire mesh, which is made of galvanized stainless steel wires. With the features of high strength, high rigidity, and corrosion, rust resistant, it is widely used for foundations reinforcing and roads reinforcing to improve concrete adhesion, prevent the emergence of concrete cracks and increase the bearing weight and so on.



Specifications of concrete slab mesh



  • Material: stainless steel.
  • Surface treatment: hot dipped galvanized or electro galvanized.
  • Variety: truss mesh reinforcement or ladder mesh reinforcement.
  • Tensile strength: 510 MPa.
  • Minimum impact strength: 485 MPa.



Table 1: Specification of Concrete Slab Mesh Length 6000 mm × Width 2400 mm
Item Wire Diameter (mm) Mesh Size (mm) Sheet Weight (kg)
WCSM01 6.3 200 × 200 33
WCSM02 7.1 200 × 200 41
WCSM03 8 100 × 100 105
WCSM04 8 200 × 200 52
WCSM05 9 200 × 200 62
WCSM06 10 200 × 200 80



Features of concrete slab mesh



  • High strength and rigidity, not easy to break.
  • Improve concrete adhesion.
  • Increase the bearing weight.
  • Prevent the emergence of concrete cracks.
  • Corrosion and rust resistant.
  • Reduce the time of installation.
  • Reduce offcuts and wastage.
  • Durable and long service life.



Applications of concrete slab mesh



  • Foundations reinforcing.
  • Roads reinforcing.
  • Building walls reinforcing.
  • Pool decks reinforcing.
  • Terraces reinforcing.



Concrete Slab Mesh With High Strength And Rigidity For Reinforcement 0



Concrete Slab Mesh With High Strength And Rigidity For Reinforcement 1
