Product Details:
|
Product: | Stainless Steel 304 Window Screen | Wire Diameter: | 0.02-2.6mm |
---|---|---|---|
Technique: | Plain Weave, Twill Weave | Color: | Black And Metal Color |
Packing: | Paper Tube Inside+ Plywood Box+plastic Bag | Material: | Stainless Steel 304 316 Wire |
Highlight: | Stainless Steel 304 window screen,Insect proof security mesh,304 stainless steel mesh roll |
Stainless Steel 304 Window Screen Dust Proof Window Screen, Decorative Window Screen
Window Screen Product:
Stainless steel window wire mesh is made of the basic stainless steel 304 wire.It is the most durable of the materials available for insect mesh and has excellent resistance to corrosion.Stainless steel window wire mesh keeps out flies, wasps, bees, mosquitoes and other insects.
Woven for optimization of 304 stainless steel material, is not easy to rust and corrosion resistance, oxidation resistance is strong, stable performance, stainless steel net uniform aperture high smoothness, surface level off is smooth, without burr, simple maintenance, strong tensile toughness, use cycle is long, high intensity, mesh accurate thickness, the same production with good reproducibility, source manufacturer, factory direct supply, quality guaranteed, Complete mesh specifications, support customization.
The wire cloth is available in both 48” and 60” widths. We can provide both full rolls and/or cut pieces depending on your requirements. The vast majority of our customers request woven mesh from 304 or 316 stainless steel, but we are also able to supply type 430 and carbon steel in most cases. Use our wire mesh chart to find the opening best suited to your application. If you need to determine the size of an existing screen, we offer metal mesh counters. They are small enough to put in your pocket and extremely easy to use. Just unfold it and set it on a piece of wire mesh. The base is a 1-inch square opening and the top is a magnifying glass. There are different units of measure marked on the interior of the base to assist you with identifying wire diameter, opening, and holes per inch.
Window Screen Feature:
Window Screen Specification:
Common Mesh Specifications ( Reference Data ) | |||||
Mesh | Aperture ( mm ) | Mesh | Aperture ( mm ) | Mesh | Aperture ( mm ) |
2 | 13 | 18 | 1 | 70 | 0.22 |
3 | 6.5 | 20 | 0.9 | 80 | 0.18 |
4 | 5 | 24 | 0.8 | 90 | 0.16 |
5 | 4 | 30 | 0.6 | 100 | 0.154 |
6 | 3.2 | 35 | 0.5 | 120 | 0.125 |
8 | 2.5 | 40 | 0.45 | 150 | 0.1 |
10 | 2 | 45 | 0.4 | 180 | 0.09 |
12 | 1.6 | 50 | 0.355 | 200 | 0.075 |
14 | 1.43 | 55 | 0.315 | 220 | 0.07 |
16 | 1.25 | 60 | 0.3 | 250 | 0.063 |
Material | Stainless steel 304 316 wire |
Color | Black White Grey etc |
Wire diameter | 0.10mm-0.26mm |
Regular specification |
11 mesh × 0.8 mm, 11 mesh × 0.9 mm, 10 mesh × 0.9 mm, 12 mesh × 0.71 mm, 14 mesh × 0.6 mm, 9 mesh × 1.0 mm. |
Width | 2', 3', 4', 5', 6', 7' |
Length | 30', 50', 100' and so on |
Window Screen Application:
Factory.Airport.Resort.Hospital.Bank.School.Nursing home.Office building.Resident building.High-end villa.Swimming pool.Mountain area.Marine area.
window screen in yard
window screen in high -grade office buildings
