60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability

Customer Reviews
Let’s talk business. Contact us and we will discuss further.

—— Dear customer

I'm Online Chat Now

60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability

60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability
60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability 60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability 60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability

Large Image :  60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability

Product Details:
Place of Origin: China
Brand Name: Cittimesh
Model Number: Woven Gabion Baskets
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Nude package,compacted before packaging. Plastic packaging outside on the pallet.
Delivery Time: 5-8 work days
Supply Ability: In abundant supply

60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability

Description
Product: Woven Gabion Baskets Materials: High Quality Steel Wire.
Mesh Opening: 60 × 80mm, 80 × 100mm And Other Customized Sizes. Gabion Sizes: 2 × 1 × 1 M, 1 × 1 × 1 M, 3 × 1 × 1 M And Customized Sizes.
Colors: Green,gray And Any Color Is Available Upon Your Request. Surface Treatment: Heavy Galvanization.Zinc Coating Plus PVC Coating.95% Zinc + 5% Al Alloy Coating.95% Zinc + 5% Al Alloy Coating Plus PVC Coating.
Gabion Height Type: Gabion Box And Gabion Mattress. Available Minimal Rock Size: 100 Mm – 250 Mm Dense And Durable Stone.
High Light:

woven gabion baskets 1mx1mx1m

,

high durability gabion baskets 1mx1mx1m

,

60 × 80mm gabion wire baskets



Woven Gabion Baskets Are Flexible, Durable and Versatile for River Slope





Woven Gabion Baskets product:



Woven gabion baskets are wire mesh containers that are filled with stones or other materials to create a strong and durable structure. They are commonly used in civil engineering projects for erosion control, retaining walls, and slope stabilization.

The baskets are typically made of galvanized steel or PVC-coated wire mesh, which provides corrosion resistance and longevity. The wire mesh is woven into a grid pattern, creating a flexible and sturdy structure that can withstand the forces exerted by the filling material.

To construct a woven gabion basket, the wire mesh is cut into panels and then folded and interconnected to form a box-like structure. The edges are laced or fastened together using wire or fasteners. Once the basket is assembled, it is filled with stones or rocks, which provide weight and stability.

Woven gabion baskets offer several advantages over other construction methods. They are relatively quick and easy to install, require minimal foundation preparation, and can adapt to uneven terrain. The flexibility of the wire mesh allows the baskets to conform to the shape of the ground, making them suitable for various applications.



Woven Gabion Baskets Features:



  • Robust and flexible structure.
  • Excellent permeability.
  • Good corrosion and rust resistance.
  • High tensile strength.
  • Good durability and long lifespan.



Woven Gabion Baskets Specification:



Product Woven Gabion Baskets
Materials High quality steel wire.
Colors green,gray and any color is available upon your request.
Mesh Opening 60 × 80 mm, 80 × 100 mm and other customized sizes.
Gabion sizes 2 × 1 × 1 m, 1 × 1 × 1 m, 3 × 1 × 1 m and customized sizes.
Surface treatment Heavy galvanization.Zinc coating plus PVC coating.95% Zinc + 5% Al alloy coating.95% Zinc + 5% Al alloy coating plus PVC coating.
Gabion height type Gabion box and gabion mattress.
Available minimal rock size 100 mm – 250 mm dense and durable stone.
Length Maximum 6 m.
Width Maximum 3 m.
Height 0.17 m, 0.21 m, 0.3 m, 0.5 m, 1 m, 1.5 m, etc.
Mesh wire diameter 2.0 mm – 4.0 mm.
Lacing wire 2.2 mm.
Standard ASTM A975-11 Standard Specification for Double–Twisted Hexagonal Mesh Gabions and Revet Mattresses.
packaging

Nude package,compacted before packaging.

Plastic packaging outside on the pallet.



Woven Gabion Basket Specification

Code Height Width Length
WOGB-1 1' 3' 3" 6' 6"
WOGB-2 1' 3' 3" 9' 9"
WOGB-3 1' 3' 3" 13' 1"
WOGB-4 1' 6" 3' 3" 6' 6"
WOGB-5 1' 6" 3' 3" 9' 9"
WOGB-6 1' 6" 3' 3" 13' 1"
WOGB-7 1' 6" 6' 6" 19' 6"
WOGB-8 3' 3" 3' 3" 6' 6"
WOGB-9 3' 3" 3' 3" 9' 9"
WOGB-10 3' 3" 3' 3" 13' 1"



Woven Gabion Baskets Applications:



  • Erosion protection.
  • Roadway and bridge protection.
  • Gravity retaining wall.
  • Riverbank controlling.
  • Noise barriers.
  • Slope paving and weirs.



60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability 0



Roadway and bridge protection



60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability 1



Slope protection



60 × 80mm Woven Gabion Baskets 1mx1mx1m Wire For Higher Loading Capacity And Durability 2



River bank protection
