BS EN 10223 Concertina Barbed Wire 3mm Dia Light Duty Structure


Concertina Barbed Wire - Higher Tensile Strength And Light Duty Structure


Concertina Barbed Wire Product

Concertina barbed wire is a type of barbed wire that is designed to be more difficult to climb over or cut through than traditional barbed wire. It is made up of two or more twisted strands of wire with sharp barbs spaced along the length of the wire. The wire is then coiled in a way that creates a spring-like structure, which gives the wire its distinctive "concertina" shape.

The design of concertina barbed wire makes it particularly effective for use in security applications, such as on the top of fences or walls, or as a barrier to prevent access to restricted areas. The coiled structure of the wire means that it can expand and contract, making it difficult to climb over or cut through without specialized tools. Additionally, the sharp barbs spaced along the length of the wire make it painful for anyone who attempts to climb over or come into contact with the wire.

It is usually used as security fence on the top of the existing fences or solid walls, in ditches on roof of tops or by itself on the ground. Concertina barbed wire can be attached onto almost all kinds of wire mesh fencing, such as chain link fence, welded wire fence, palisade fence or expanded metal fence to achieve high level security.

Concertina Barbed Wire Feature

• Simple and light duty structure.
• Sharp edge, higher tensile strength.
• Anti-corrosion, difficult to cut or destroyed.
• Economical and practical.
• Various colors available.
• Easy to install and long service life.

Concertina Barbed Wire Specification

• Material:Iron wire, mild carbon steel wire, steel wire, stainless steel wire.
• Wire shape:Round with small protrusions.
• Strand structure:Single strand.
• Line wire
  • Material: Mild carbon steel wire, steel wire or stainless steel wire.
  • Wire diameter: 3.0 ± 0.05 mm.
  • Tensile strength: 1235 N/m2.
  • Galvanization: 275 g/m2.
• Barb
  • Material: Iron wire.
  • Wire diameter: 2.0 ± 0.05 mm.
  • Tensile strength: 350 N/m2.
  • Length of barbs: 13–20 mm.
  • Distance between barbs: 60 mm ± 16 mm.
  • Galvanization: 240 g/m2.

• Standard:BS EN 10223.
• Package:Packed with bailing strip and then covered with PP woven bag, or according to your requirement.

Concertina Barbed Wire Application

Concertina Barbed Wire is used in airport security fencing,prison security fencing,farm and ranch security fencing,highway security fencing,railway security fencing,residence security fencing,factory security fencing,military site security fencing.

Concertina Barbed Wire for highway
